BUMV-4X1-1080P is a 4×1 HDMI multiview switch that allows four HDMI sources to be displayed simultaneously on a single monitor. Supporting full 1080P resolution, it provides flexible layouts such as quad-view or picture-in-picture (PIP) for monitoring, control rooms, and security applications.
| Specification | |||
| Item | Description | ||
| Product number | BU-FM-120 | ||
| Features | Transmission signal category | HDMI video | |
| Transmission channel | 1 way | ||
| Transmission distance | 120M | ||
| Transmission delay | <100ms | ||
| Transmission characteristics | 1TX to multiple RX, support cascading, support network cable switch connection | ||
| Power section | Power supply | Power adapter | |
| Power Speed Coupler | Voltage range | 5VDC | |
| Power consumption | Transmitter (TX): ≤3.5W; Receiver (RX): ≤3W | ||
| HDMI performance | Support HDMI version | HDMI1.3 | |
| Support HDCP version | HDCP1.4 | ||
| Support HDCP version | 24-bit/dark 30-bit/dark 36-bit | ||
| Support audio format | Left and right stereo audio | ||
| Maximum transmission rate | 10.2Gbps | ||
| Audio signal transmission format | Left and right stereo audio | ||
| Input and output TMDS signal | 0.5～1.5Vp-p(TMDS) | ||
| Input and output DDC signal | 5Vp-p(TTL) | ||
| Input cable length | ≤5m (AWG26 HDMI1.3 cable standard) | ||
| Output cable length | ≤5m (AWG26 HDMI1.3 cable standard) | ||
| Protection | Surge Protection | ||
| Lightning protection | |||
| ESD protection | |||
| Operating environment | Operating temperature | 0～60℃ | |
| Storage temperature | -20～70℃ | ||
| Humidity (non-condensing) | 0～95% | ||
| Body attributes | Dimensions (length × width × height) | 109×58.5×25mm | |
| Material | Ferroalloy material + crystal panel | ||
| Treatment process | Sandblasting | ||
| Colour | black | ||
| Weight | TX: 120g, RX: 125g | ||
| Reliability | Mean time between failures (MTBF) | >30000 hours | |
